I already posted some preliminary thoughts about this unit in two other threads, one dealing with my Watkins Generation 4 speakers and the other discussing my "Graham Audio LS8/1 Signature Edition & a New System". Now that the Lyndorf is, I believe, fully broken in/settled in, I thought I would create a new home for any further discussion of this unit here. I did not want discussion of this item to get "buried" in other threads since I think the Lyngdorf is quite a significant change/addition to my system. I have not changed my mind about anything I said in those preliminary thoughts posts. I will cross post those preliminary thoughts below and then carry on the discussion from there.

  • Like
Reactions: Holmz
A Further Simplified System: Lyngdorf TDAI 3400

Consider this a preliminary report. I have further simplified my main audio system by replacing the Lumin X1 streamer/DAC, Lumin L2 Music Library & Network Switch, and bridged pair of Benchmark AHB2 amplifiers with a Lyngdorf TDAI 3400. This reconfiguration allows me to keep all the electronics on my small rack and eliminate the amps sitting on the floor in front of the rack. It also eliminates four power cords, cleaning up the nest of cables behind the rack. Each of my PI Audio UberBusses now drives only a single component and each of these are driven by a separate dedicated circuit on the same phase of my electrical service. The TDAI 3400 is driven by one dedicated circuit/UberBuss and the GigaFOILv4 Inline ethernet filter, powered by 5V output of Farad Super3 linear power supply is driven by the other dedicated circuit/UberBuss.

The complete new current system configuration is linked to from my signature on this post.

This is the third time I've used Lyngdorf equipment. I used a TDAI 2170 to power my Stirling Broadcast LS3/6 speakers and feed my Audio Kinesis Swarm subwoofer arrays. I also at one point used a Lyngdorf SDA 2400 amp to power my Harbeth M40.1 speakers in another room. Both of those experiences were highly positive with the exception of Room Perfect in the TDAI 2170. I always found Room Perfect to create an unneeded and sonically objectionable peak in the response in the 4 kHz range.

At this point I am exceptionally pleased with my purchase of the Lyngdorf TDAI 3400. It sounds fabulous and all the functions I need seem to work in a glitch-free manner. Since it retails for $7,500, replaces Lumin and Benchmark equipment retailing for about $26,000, and sounds even better than that equipment, I'd say it is a bargain for me.

I will need to wait another week or so for my UberBuss power treatment units to warm up/settle in after being disconnected from power for an extended period as I did when I dissembled things and inserted the Lyngdorf. It also takes about that long or longer for the Deoxit Gold-treated connections to fully "cure," so I'm not yet getting the "full effect." But even at this point, I'm very pleased indeed.

Some details and observations:

I received my TDAI 3400 early last Friday. I spent the day dismantling my system, photographing and packing up the Lumin and Benchmark items, and moving them to our basement. I did manage to get the 3400 mostly set up late Friday evening and finished the job early Saturday morning. I did not employ Room Perfect until Sunday.

A comment on the packaging of the Lyngdorf: Not since some PS Audio equipment I once owed have I seen packaging this simple yet bombproof. The double-boxed container primarily uses cardboard and thick clear plastic membranes above and below the chassis to form a springy, air-surrounded environment for the electronics inside the box. Very safe and very easy to unbox.

Before I implemented Room Perfect I didn't really expect the bass to be both stronger and yet better defined. But that is what I heard right from the first few notes. There was more meat on the bone. And there was yet more dynamic contrast. Roon programming sounded yet better this way. High frequencies seemed about the same--very nice indeed with no increase in nasties or other artifacts. I had the sense of great reserve power, at least as much of the "Hoover Dam" sensation as before.

Another great way to play Qobuz streaming, through the Lyngdorf, besides using Roon, is via the Mconnect app. That way sounds at least as excellent as via Roon. You can play Qobuz and Tidal sources via Mconnect using the UPnP input function of the TDAI 3400. Tidal Connect is also a great alternative to Roon when streaming from that service with sonics at least as good as Roon. The Lyngdorf allows Tidal Connect.

[Continued in next post]

Then I implemented Room Perfect. Whoa! Full stop.

The sonic changes from implementing Room Perfect in Focus mode were all to the good. VERY GOOD! This is a VERY significant improvement to what was already truly excellent sound except for what Room Perfect found to correct and corrected.

There is now much more meat on the bone. It apparently at least partially filled in a dip I had in the upper bass/lower midrange so that the sound is more fulsome, making the frequency balance of the Watkins Generation 4 speakers I'm currently using much more like the balance of the Graham Audio LS8/1s without Room Perfect but positioned at the same distances from the walls. Lower voices, cellos, piano left hand and most any music with significant low end benefits from presenting the "power range" (say 100 to 300 Hz) and lower midrange at proper relative levels. All music sounds fuller, more powerful, more weighty and larger. Bass definition is also further improved with the tune of note-to-note walking bass becoming yet easier to follow. All this correction was made without adding any undue midbass bloat or thump. Low bass is not much affected--the Watkins speakers still roll off below 40 Hz, in other words, but the overall impression of bass weight is greatly enhanced.

Unlike my experience with the TDAI 2170 years ago, I hear no excess high frequencies injected by Room Perfect. Besides the magic in the lower frequencies, imaging is firmed and staging is considerably more 3-D. That's going some since the Watkins presentation was already by far the most 3-D Ive heard from any speakers in this room.There's also a general sense that the sound is more "present" without any audible peaks in the mids. Altogether using Room Perfect in the TDAI 3400 is a great success for my system!

I use a Cardas-style set up and have for years because this maximizes realism of imaging and staging from most speakers in my room. Those sonic aspects are the most important to me. I'm not so sensitive to bass balance as long as there is no midbass boom, which there wasn't. The Watkins speakers are on 30-inch stands. In my room that puts the woofer about the same distance above the floor as it is from the side wall. Perhaps that causes a null or dip in the upper bass/lower midrange, but that's just speculation. I know putting the Graham speakers on the 20 inch Skylan stands I first used and the same distance from the walls caused a bit of the same kind of dip/null, but not to the same extent. Moving the Grahams to the shorter Graham stands made the Grahams nice and full sounding.

If you have used Room Perfect in the past and have not achieved altogether positive Room Perfect results, check your software version. The current one, and the one I'm using in the TDAI 3400, is version 3.3.0. I also strongly suggest that you try the following "trick" set up for Room Perfect if in the past Room Perfect was emphasizing the highs or in some other way producing less than totally satisfying results.

Lyngdorf's instructions for setting up Room Perfect, which I have followed in the past call for placing the microphone at "random" room positions and orientations with respect to the speakers after the initial measurement at the listening position. That is NOT the way I set it up this time. I should note that Lyngdorf admits these days that if you have an acoustically treated room (as I do), you can avoid having the Room Perfect correction end up with excess highs by always aiming the microphone between the speakers regardless of the "random" positions of the microphone within the room.

For my current Room Perfect set up, I put the front tip of the microphone where the center of my head is between my ears when I'm in the listening chair. I pointed the mic level and straight forward to the point on the wall behind the speakers, midway between the two speakers. I did not move the microphone for any of the measurements. I started out with the volume set at minus 30, but Room Perfect said that was too low and to set the volume at minus 12 dB. That was quite loud, but seemingly safe for the speakers. I was running the measurement from my computer desk outside the listening room, so the room was empty of people and with the door to the listening room shut (my usual way to listen when I'm in that room) it was not loud at all outside the room. Room Perfect told me it had 100% room knowledge after the Focus measurement and one room measurement, but I ran two more room measurements anyway, again not moving the mike. After the third room measurement (a total of four measurements including Focus), Room Perfect said I was done and should exit. The entire Room Perfect measurement process, including setting up the mike, which is the most time and detail intensive part, only took about half an hour.

In walking around the room, I hear not much variation in bass level with Room Perfect set on Focus. I worried that it might sound too bassy outside the listening postion, but that is not the case.

So I guess my effort to "fool" Room Perfect about how to adjust the response worked. I love it when a plan comes together! I will not be going back to the Lumin/Benchmark equipment!

Let me add that before purchase I was aware of the less-than-stellar measurements of the TDAI 3400 reported by Audio Science Review (ASR) and some others. I was also aware of the stellar subjective reviews from other sources. I also note that ASR at least partially recanted once the author heard the results of Room Perfect on his own home system, then giving the 3400 his recommendation.

Before purchasing my Lyngdorf TDAI 3400 I also heard a friend's TDAI 3400 set up with the Graham Audio LS8/1 speakers and was quite impressed. Now, having heard the 3400 in my own room, all I can say is that whatever objective flaws the electronics may reveal on the test bench, the Lyngdorf TDAI 3400 yields subjectively amazing results in my listening room.

A picture of my newly further simplified system is attached. Note that this system is much closer in configuration and price to the type of system Bill Watkins uses to demonstrate the Watkins speakers at his retail store. I estimate the total cost of this newly simplified system at about $15,000, including all the acoustical treatment and electrical tweaks.


My original goal in simplifying my system--which began with my abandonment of my Sanders 10e speakers for the Graham LS8/1 speakers--was to explore whether components which were much more manageable in size, weight, and bulk, and thus more manageable for me to handle as I age could perform in my small room on par with the best larger speakers.

That goal was, as it turned out, quite easy to reach with the Graham LS8/1 speakers. The Grahams, driven by less expensive, much lighter/smaller amps than the Sanders Magtechs, proved capable of surpassing the sound quality I had from the Sanders speakers. First the Audio by Van Alstine DVA M225 monoblocks, and then a pair of bridged Benchmark AHB2 amps used as monoblocks filled this role.

Then I discovered that, except for the bottom octave, the 1/3 the cost, 1/3 the size, 1/2 the weight Watkins Generation 4 speakers were at least the overall sonic equal of the Graham LS8/1s in my room.

Now the Lyngdorf TDAI 3400, at all of 18 pounds, has proved to be at least the sonic equal driving the Watkins of a combination of the Lumin X1 streaming DAC, the Lumin L2 Music Library & Network Switch, and the pair of Benchmark AHB2 amps.

My system is a streaming-only system. I don't need or have any external HDMI, digital, or analog components to connect to the Lyngdorf. Thus, I'm not using any of the stock unit's analog or digital inputs or outputs and thus certainly don't need the optional high quality analog board or the HDMI board. The retail price of my "basic" TDAI 3400 is currently $7,500. Not cheap, certainly. But the Lyngdorf replaces streaming and amplification electronics with a current MSRP of almost $26,000 so in my estimation, for my system and needs, it's a bargain.

And the Lyngdorf potentially can do so much more, serving as a full-fledged preamp for both analog (including phono) and digital sources, digital crossover for added stereo subwoofers, as well as quite flexible automatic or manual electronic equalization and "voicing" of the speakers. It is a true Swiss Army Knife of electronic equipment. Not since the TacT RCS 2.2XP have I owned a "preamp" with this kind of flexibility, and the Lyngdorf adds an amazingly capable two channels of powerful amplification to the package.

And then there's Room Perfect. My first experience with Room Perfect, via the Lyngdorf TDAI 2170 I owned a number of years ago, was less than totally satisfactory. At that time I was unable to keep Room Perfect from adding unwanted extra emphasis to the mid-highs. It always added a measured and subjective increase in response centered around 4 kHz. I had to use other electronic EQ to get rid of this problem, adding to system complexity and reducing system transparency.

But that was then and this is now. In the TDAI 3400, my first attempt to set up Room Perfect took only about half an hour total for microphone set up (by far the most tedious and exacting part) and measurements. And with the set-up trick I described in post #3 above, it produced absolutely STUNNING improvements to the sound of my Watkins Generation 4 speakers in this room, even though I thought the Watkins sounded pretty darn fine before the Lyngdorf and Room Perfect. So much sonic improvement with so little effort! I've used many electronic equalizers over the years but this current version of Room Perfect is both the easiest to implement by far and yields what to my ears by a good measure the most sonic improvement. I hear no downsides whatever to using Room Perfect in the TDAI 3400.

More important than it once was, the ability of the Lyngdorf to conserve electricity when idling makes the unit extremely environmentally friendly. The case is never more than only very slightly warm to the touch. Not much electricity is being wasted through heat. I do not feel at all guilty about leaving the Lyngdorf on and playing 24/7. And even if the air conditioning is not running and my listening room door and window are shut, this small room does not get overly warm during extended listening sessions.

My initial sonic impressions I expressed in posts #2 and #3 above have been confirmed now that the Lyngdorf and its electrical connections are warmed up/broken in/settled in. If anything, the sense of ease and analog-like smoothess now exceeds that of the Lumin/Benchmark equipment.

I am constantly struck by how smoothly the streaming functions of the TDAI 3400 are integrated. It is simple and quick to switch from any form of streaming to another without any functional or sonic glitches at all.

Roon provides an easy way to listen to most anything except a few subscription services like Siriux/XM and JazzRadio, for which AirPlay is required. Unless I want to be very picky indeed, I usually listen via Roon, especially if I'm in internet radio surfing mode. For many stations, in ten seconds or less, Roon provides a three-click method of moving from the low-res internet radio stream to CD or better quality of the same program streamed from Tidal or Qobuz

If I want to be picky about subjective sonic quality, with the Lyngdorf, the Tidal Connect input provides the absolute highest subjective quality for Tidal sources. The sonic quality of Mconnect via the Lyngdorf's UPnP input is the highest available for Qobuz, but only very slightly better than that of Roon.

For internet radio sources, I can compare the Roon Live Radio version with the vTuner, airable, and AirPlay versions. I generally prefer the sonics of those services which do not upsample/resample the stream of the particular station. While Roon makes available the highest quality internet radio streams, Roon unavoidably upsamples/resamples radio streams of less then FLAC quality to 24 bits from the usual 16 bit native version. Roon's upsampling/resampling of these streams seems to basically negate any advantage it might achieve by allowing streaming from higher bit rate streams. That said, the sonic quality of all the methods of streaming via the Lyngdorf is as high as I've experienced and the Lyngdorf makes such comparisons easier than most other streamers.

I should mention that if you have not compared the relative quality of Tidal Max and Qobuz HiRes streams lately--that is, since Tidal dropped most of its MQA versions--you may be pleasantly surprised that Tidal streams are now fully the equal if not better sounding than the Qobuz ones. Tidal streams have a bit more bass warmth and lack the bit of edge in the highs common to Qobuz HiRes, while having equivalent overall detail and transparency.

Last edited:
When I was researching and then searching for a solid sate amp to replace previous (mainly) SETs, I bought or borrowed 12 amps of all Classes, including the Benchmark AHB2 and Lyngdorf 3400.

For my taste the BM was a non-starter, despite its accuracy, dead silence and other nice features. My single-line summary for each amps shows "drearily dull" against the BM. It was an amp I was never inclined to turn up the volume and boogie to - music was more like Musak!

The 3400 fared much better, although I was only using its amplifier section. However, after following the RoomPerfect guidelines, my conclusion was that RP sucked the life out of the music after taking 2 sets of measurements. Perhaps, if I'd experimented more with alternative mic positioning, as you have, I may have got better results.

Despite the 3400's good sound, I chose a different amp that also offers the "all-in-one" features of the 3400 - but better overall with my own, very different speakers.

But with regard to "room correction" DSP (DSP can NEVER improve a room, can it?), I have found that attention to physical room features offers a MUCH better way of correcting room anomalies than messing with a nice accurate signal. We should be confident that well chosen (for the room) speakers and an accurate amplifier should deliver great sounds. Messing with the signal goes against the whole ethos of brands that build great equipment in my opinion. I'm not expecting many to agree, but I don't use the Dirac Live in my own amp, because music sounds more exciting and dynamic (top end sparkle), albeit possibly slightly less bass accuracy to a microphone's ears without a DSP filter.

DSP does gave a place in AV / HT systems with multiple speakers that most of us are unable to properly set up, but that shouldn't be the case with 2-channel music produced by well-selected kit. It's also a boon for DIY speaker builders because the software has no idea what the anomalies are caused by - it just adjusts the signal to compensate as best it can, thus "correcting" the likely deficiencies of a home-built speaker system. Also, it could be used in the bass-only section of active or hybrid speakers such as your earlier D&Ds or my own Avantgarde XDs, where the top part of the frequency range can receive an unmolested signal from the amp, while the bass alone gets a DSP'd (messed-with) signal!

I hope you are enjoying your present system and it continues to provides better sound at lower cost than your earlier ones.

Last edited:
I enjoyed time with the 2170, prior to that the 2200 and prior to that the Tact RCS2.0

I liked the versatility of the 2170, particularly the option to use its RCA outs to feed a pair of monoblocks or a stereo amp, using the inbuilt amplification to power passive subs. With vintage Altec Valencias, that gave me the opportunity to run them with SET amps while extending the bottom end via a pair of modified Aerial SW12 passive subs, with everything pulled together via RoomPerfect.
I also experimented with the active crossover functionality built into the 2200/2170 to run the 2-way Valencias with 300b SET monoblocks on the horns and the inbuilt digital amplifier controlling the Valencia’s 15” woofers.
Superbly versatile and very good sounding.
Glad to hear that you’re enjoying your 3400.

Yes, the speakers I tend to prefer are very different from Avantgardes. Heard from five feet away or less, as I usually listen in my very small room, most speakers reveal their inherent problems in an unavoidable way. This is why in this room I have focused on using speakers which speak with one voice--that is, where I cannot easily hear out the contributions of each driver--during near-ish field listening. The Avantgardes are terrible at this, as are most all large horn speakers--the drivers are just too far apart to cohere from ten feet away, much less five or less feet away.

As far as the concept of equalization is concerned, all crossovers are equalizers. The only difference between DSP and traditional analog crossovers which primarily use resistors, capacitors, and inductors in the signal path is whether the EQ is done in the digital or analog domain. If the designer does a decent job, he adjusts the speaker's response to provide the desired sound in whatever testing situation(s) he uses. I've found that in terms of crossovers, in near-ish field listening, simpler is subjectively better. These days only a first-order time-aligned arrangement (such as in the Watkins Gen 4) seems coherent enough; either that or a design which has no crossover at all in the critical part of the frequency band. My Graham LS8/1 speakers have no crossovers at all from deep bass up through 3.5 kHz.

Moving speakers and the listening position around in the listening room or adding absorbing or diffusing acoustical treatments is not electronic equalization at all, of course. Such manipulations work in the acoustical or mechanical realm. You are mostly simply adjusting the action of room modes and room surface reflections on what you hear from the speakers in the sweet spot. Most people try to arrange things so as to provide both a good frequency balance and good imaging/soundstaging.

I freely admit to giving greater priority to the spatial characteristics in my set ups. What I've recently found with Room Perfect in the TDAI 3400 is that I can have my cake and eat it, too. No longer do I have to be content with less than fabulous bass smoothness in order to achieve optimal imaging and staging. I really don't hear any electronic glaze, flattening of the presentation, or any other problems which could be attributed to Room Perfect's DSP when I flip back and forth between the Bypass and Focus settings of Room Perfect, something the Lyngdorf allows in a fraction of a second.

Audioresurgence, I enjoyed my time with the Lyngdorf TDAI 2170 also. I used its flexibility to smoothly blend my Stirling LS3/6 speakers with the AudioKinesis Swarm subwoofers and their dual outboard amps. Room Perfect was literally the only thing I didn't like about the 2170. Either Room Perfect has since been "perfected" in the 3400, or my trick in avoiding positioning the measuring microphone randomly has now made Room Perfect literally perfect for my situation.

If interested, you can read about my experiences with the TDAI 2170 years ago in my threads dealing with the Stirling LS3/6 and blending those speakers with the AudioKinesis Swarm subwoofer array here, here (point 8), and here.

I have just started experimenting with the Lyngdorf Voicings. I have used the Neutral Voicing most of the time. I do find, however, that for some brighter classical recordings, Music 1 or even Music 2 can take the "edge" off and sound more natural.

With Room Perfect working as well as it does in my system, I seldom feel the need for adding more bass, as long as the recording is not really thin sounding and I'm listening at a level I find natural sounding. I will have to experiment more with the thin sounding recordings. The Bass Voicings sometimes do sound better on those and perhaps I should experiment with the Action 1 Voicing for quieter and late-night listening.

For classical music fans, who also like exploring internet radio stations, I call your attention to two stations I have found enjoyable in recent months. The Performance Today stream can at times have a lot of talking, but the music this station plays is more unusual than that played by most classical stations and the ensembles playing are little heard elsewhere. The sound is decent for a low-resolution Internet radio station. You can find it within the TuneIn app. Then, if you input its URL into your My Live Radio station list in Roon, you can listen to it via Roon.

The identity of the Performance Today radio stream within TuneIn is a bit ambiguous. The one I'm talking about is:

https://tunein.com/radio/PerformanceToday-s309263/

As to Roon versus non-Roon listening, I've noticed that low-res internet radio streams usually sound best via the Lyngdorf (and the Lumin equipment) when they are not upsampled/resampled the way Roon always does. Generally the best sounding low-res internet radio streams are ones where the Lyngdorf screen displays PCM 16 44.1 kHz. Via Roon, the Lyngdorf screen will show all such streams as PCM 24 since Roon always upsamples/resamples such streams to 24 bits from their native 16. Very few internet radio streams are natively 24/44.1. or 24/48.

TuneIn stations generally sound pretty good via the Lyngdorf's AirPlay function--better than they did with the Lumin equipment. I'm not sure how much of that is just the Lyngdorf and how much is several software updates TuneIn has done lately which it claims improve sound quality.

The other of my favorite classical stations I want to mention (favorite based on a combination of programming and sound) can be found via the Lyngdorf's vTuner app by searching for "MPR Classical 99.5 Minneapolis". Make that an input preset on the Lyngdorf and it won't be upsampled/resampled by Roon if you play it via its dedicated radio station input. This station uses very little if any compression and subjectively has quite low distortion for a low-res signal. While it, too, sometimes has a lot of talk related mostly to the Minneapolis area, most of the time it either streams its own curated streams of classical MPR/NPR programming or shares programming with the Classical 24 service streamed on many other internet radio stations. The music generally sounds best on this station, however, due to the lack of compression and subjectively very low distortion. (Another version of this same stream is called Your Classical MPR, but that version does not sound quite as good. Yet another version which often plays the same programming is known as Your Classical Radio, but it is much more compressed and thus doesn't sound nearly as refined and natural.)

As to Hi-Res streaming services, users who exclusively or mainly use Qobuz as opposed to Tidal may want to try a trial Tidal subscription. Since Tidal dropped most of the MQA versions, Tidal's true high-res and Redbook versions often by comparison sound just a bit fuller in the low end and definitely less "edgy" in the high frequencies compared to the equivalent Qobuz versions. This is evident via Roon comparisons and more apparent via Mconnect and especially via the Tidal Direct input of the Lyngdorf. You may find less need for reducing brightness with Tidal, in other words, since the "edge" fairly common to Qobuz versions is also reduced by some of the non-Neutral Lyngdorf Voicings, such as Music 1 and Music 2.

By the way, the Lyngdorf does the first unfold of MQA material via its MQA core decoder function. Unlike the Lumin X1 I had, however, the Lyngdorf is not an MQA renderer and thus does not fully unfold encrypted MQA material. The Lumin equipment sounded better with MQA material than the Lyngdorf since the final unfolding pulls out excess brightness and creates a more relaxed-sounding presentation. But most of the MQA material has now been removed from Tidal; I've only run across a few remaining MQA titles and I'm sure those will drop out of the service soon since Tidal has committed to replacing the MQA versions with their Max true high-resolution versions.

I love how the Lyngdorf makes moving from one stream to another so easy. I'm also enjoying experimenting with the various sonic "flavors" the Voicings function provides.

Last edited:
The sound of my Lyngdorf TDAI 3400 has continued to improve over the last week: clearer yet overall, punchier and better defined bass, more natural tonality overall, better-yet dynamic contrasts, and more three dimensionality/envelopment in particular. I now have over three weeks continuous playing time on it and it now definitely provides the best sound I've ever heard from my Watkins Generation 4 speakers on all my streaming sources. I have sold my Lumin X1, L2, and Benchmark AHB2 amps without any regrets.

The Lyngdorf TDAI 3400 is often referred to as an "amplifier." Yes, it is that, and a very capable one at that, "doubling down" in power from 200 wpc at 8 ohms to 400 wpc at 4 ohms. But it is so much more:

Equalizer

Room Perfect
is the most powerful, easiest to use, automatic equalizer I have ever used and the results at least match what I've ever been able to achieve in terms of naturalness with any manually adjustable equalizer I've used, and I've used many. See this thread and add to that list the EQ available within the Dutch & Dutch 8c, as well as REW and the dBX VENU 360 used as part of the Sanders 10e speakers. The primary use of Room Perfect is to eliminate how your listening room "pushes around" the frequency response of your speakers, particularly below about 500 Hz, but also with important tweaks above that frequency. As I've said in prior posts on this thread, as implemented in the TDAI 3400, I hear no downside whatsoever to the implementation of Room Perfect in this unit. Room Perfect also automatically uses DSP to adjust for path length or other time-domain discrepancies of the left and right speaker outputs as heard from the listening position.

Besides Room Perfect, the 3400 offers many pre-configured Voicings to modify the sound in ways which may make the results more natural sounding with certain types of music. Music 1 and Music 2, for example, back off the presence range a bit or more and make lots of large-scale classical music recordings sound more like what one hears from an audience perspective in a concert hall. In addition, you can manually modify these Voicings and create up to 32 other custom Voicings of your own design using combinations of parametric filters. One Lyngdorf dealer I know uses Voicings he created to provide Loudness Compensation curves which can be used to customize the relative bass level for various listening levels which are less loud than what the recording was probably mastered to anticipate.

Crossover

The TDAI 3400 provides DSP-implemented low- and high-pass crossover filters for blending mono or stereo subwoofers and stereo main speakers. The user can adjust these filters manually, or let Room Perfect do the job automatically. From prior experience with the TDAI 2170 used to mate the Stirling Broadcast LS3/6 main speakers with my AudioKinesis Swarm four-subwoofer array, I know that the Lyngdorf software is extremely effective and transparent in mating mains and subs.

Preamp

The 3400 is a full-featured analog and digital preamp with both analog and digital inputs and outputs. Adding the high quality analog input board and the HDMI board further increases the flexibility of the 3400 as a system preamp. It is capable of handling even moving magnet (or high output moving coil) phono inputs.

DAC

The 3400 acts as a traditional DAC when outputting bass signals to subwoofers via its analog outputs.

When used in a standard two-speaker stereo configuration, the TDAI 3400 really doesn't use a traditional DAC. The unit in such a configuration is called a "power DAC," converting the internal 24/96 digital via PWM to analog just before the speaker outputs. The unit does not embody a traditional volume control or even the DSP-processed Leedh volume control used in the Lumin products. The 3400 adjusts its output voltage/wattage (and thus the SPL you hear) by reducing the voltage input to the power DAC. Because of this, the 3400 does not lose resolution at lower volume levels the way traditional digital volume controls do.

MQA Core Decoder

For the remaining Tidal MQA offerings, the Lyngdorf acts as an MQA Core Decoder, displaying whenever this MQA function is active. It does an excellent job sonically in this respect, superior to what Roon's own Core Decoder does. Full rendering, such as is provided by the Lumin X1, eliminates a bit of residual brightness from MQA recordings, but the results via the Lyngdorf Core Decoding are nonetheless very satisfying, often sonically bettering the results of straight FLAC 44.1/16 Tidal streaming, even when the MQA is only 44.1/16 resolution.

Streamer

The Lyndorf TDAI 3400 is also a very flexible streamer, both for your local music files and internet sources. It's only "weak" spot is USB-connected local file servers.

To handle the "bad news" first, to be readable by the Lyngdorf, USB-connected drives MUST be formatted in FAT32. The Lyngdorf will not read such sources formatted in ExFAT or other formats. Even with FAT32 formatting, the Lyngdorf's ability to properly render/reproduce the album art for recordings is, at best, hit or miss. The manufacturer admits this problem.

The way I get around this problem is two fold. First, I don't use any USB cables. The Lyngdorf is fed via ethernet both from the Web and via my Roon Core. Second, I connect my USB file server (in my case a 1 TB USB thumb drive) directly to my Roon Core. This way, all my owned local music files are perfectly integrated with my Tidal and Qobuz favorite recordings when using Roon for playback. All album art and indexing functions work as anticipated. I thus plug my USB thumb drive holding my owned WAV music files directly into one of the USB ports of my Poor Man's Roon Nucleus Plus.

Otherwise, the TDAI 3400 provides a smoothly integrated streaming experience from any streaming source with never a glitch when switching from one source to another. Other streamable sources include:

Tidal Connect: This is marginally the best-sounding way to playback Tidal files of any resolution--FLAC, higher resolution, or MQA. You use the Tidal app residing on your control device (in my case an iPad Pro) to stream.

Mconnect: This $6 app (available from the App Store or Google Play store) provides truly excellent playback of both Qobuz and Tidal FLAC and higher-resolution files and usually sounds marginally superior to Roon playback. This app uses the Universal Plug and Play (UPnP) input function of the Lyngdorf.

Roon: Roon provides the most universal streaming source, capable of playback of your local music files, Tidal and Qobuz files, and most internet radio sources. The notable exceptions are some streaming internet radio sources behind paywalls, such as Sirius/XM stations and JazzRadio. Roon seems to have higher fidelity via the Lyndorf than it did via my Lumin equipment.

Spotify: The Lyngdorf treats Spotify as a "native" streaming source. Thus, if for some reason you prefer this service to Tidal or Qobuz, you can stream it directly through the Lyngdorf without using AirPlay. Spotify is a separate input on the Lyngdorf.

vTuner and airable: The Lyndorf treats these two internet radio station aggregators as "native" sources. Any station playable from either of these services does not rely on Wi-Fi or AirPlay for playback. You can identify up to ten stations from these aggregators as "favorites," which will add up to ten additional inputs to the 3400, one for each favorite station. Any other station from either of these aggregators can also be streamed at will by identifying and selecting the station. The indexing available for both aggregators is excellent, so particular stations can be found with ease if they are within the "universe" of stations available through either aggregator.

AirPlay: This is the solution for streaming Sirius/XM, JazzRadio, and other internet radio sources behind a paywall. While you might think that fidelity would suffer when streaming in this manner, I do not detect any quality decrease for any stations below the FLAC 44.1/16 resolution level, which is most internet radio stations. Some stations actually sound best through the Lyngdorf this way even when there are other streaming options; SomaFM stations are one example, and MPR Classical Minneapolis is another. This has also been my general experience with prior use of AirPlay with my Lumin streamers, but the Lyngdorf seems to do an even better job at this. I suspect that the reason AirPlay performs so well in my system is that even connecting my iPad's output to my home network via Wi-Fi, just before the signal gets to the Lyngdorf it passes through my GigaFOILv4 Inline Ethernet Filter whose internal fiber optic link eliminates a lot of EMI/RFI "hash" carried along the lengthy ethernet connection from my router to the Lyngdorf.

TuneIn Radio: This is a special case of an internet radio station aggregator available only via AirPlay. TuneIn has recently made major strides in sound quality and I sometimes find stations played through TuneIn to sound superior to the same stations played via Roon. One reason for this may be that TuneIn does not resample/upsample internet radio sources of less than FLAC 44.1/16 quality to 24 bit bit depth as Roon automatically and undefeatably does. One example of such a station is the excellent sounding (for a low-resolution stream) feed of WSPJ St. Pete Jazz.

Last edited:
Another useful feature of the Lyngdorf TDAI 3400 is its included remote control wand. This hand-held remote control can either be activated or deactivated in the 3400's settings. Once activated, it can operate either via Bluetooth or infrared signals. The functionality of this remote wand is detailed on page 13 of the 3400 manual.

I bring this up because, like prior streamers I've owned, the sound quality of all streamed sources marginally increases when the streamer's internet control device (in my case an iPad Pro) is turned off (as in really off, not just closing the apps controlling the device). With the Lyngdorf, this sonic increment is as small as I've encountered, but it is still there.

I've also noticed that deactivating Bluetooth functionality of various devices (e.g., phones and tablets) also increases sound quality of the streamer. It is thus nice that the Lyngdorf remote has an option for infrared-only operation. I use the remote wand in infrared mode. I hear no sonic difference between this infrared mode of operating the remote wand and actually disabling the remote wand.

Among the functions controllable via the remote wand are:

-Volume up/down
-Bass and treble "tone control" adjustment
-Toggling among Neutral vs. various Voicing selections
-Room Perfect settings (toggling Bypass, Focus, Global)
-Menu selection and navigation
-Mute/unmute sound sent to headphones or speakers
-Toggling among active sources, including 10 radio station presets
-Play/pause or skipping back and forth within the currently playing track in the media player
-Choosing information displayed on the front panel display of the unit (the front panel, by the way, is extremely readable, even from 10 feet away)

No, the remote wand cannot move you around within Roon or other streaming services. But once you've settled on something to listen to, the remote wand give you all the functionality you need to maximally enjoy the playback with the maximum fidelity possible with the TDAI 3400.

Just how good is the streaming sound from the Lyngdorf TDAI 3400 in my system? At this point in my experience with the unit I am confident that the sound is equal to or better than that of any other streamer I've ever used. I will use one particular recording as an example: Old & In the Way, Live at the Boarding House, the Complete Shows:


This recording contains all the material which was released on the more familiar and shorter "Old & in the Way" CD, plus much more:


This is an all-acoustic instruments analog recording from dates in 1973, recorded with a live audience in a club-type venue with relatively few microphones and obviously not much extraneous audio processing, being advertised in the liner notes as a "true stereo" recording.

I have listened to this recording, particularly the cuts on the shorter Old & in the Way CD, for decades on every iteration of audio system I've had over those years. I am intimately familiar with these recordings. Over the years, my systems have increasingly removed extraneous brightness/edge from the sound, made the recording venue's room sound more obvious, increased the lifelikeness of the tonality of voices and instruments, clarified bass lines, revealed increasing subtlety in each player's musicianship, as well as revealing more of the "side chatter" among the live audience and band, both in terms of word intelligibility and placement in space.

The Lyngdorf reveals a whole new layer of natural tonality and detail in all these areas. It also more clearly differentiates the spatial and imaging characteristics of the two live recording dates captured on the Complete Shows recording. One date separates the images of the musicians left to right a bit more, resulting in just a bit of a "hole in the middle" effect unless a soloist moves to center stage. The other date has everyone seemingly evenly distributed across the sonic stage. The Lyngdorf further expands the dynamic range of each player and further solidifies their stage placement. The subtlety of the fiddle/violin artistry of Vassar Clements is further revealed and enhanced. The "side chatter" of audience and band is shockingly clarified, with previously unheard, much less intelligible, comments now clearly heard both in terms of words and spatial placement. Everything about these recordings "hangs together" better than I've ever heard them before, increasing musical joy.

@tmallin after having the Lyngy MP-50 I was pretty tempted to just go with a 3400 and replace the PrimaLuna Dialague HP Premium.
However I have a phono amp, preamp stack that I got at about the same time, and I have a mixed 2-Channel + HT.
I suspect that the two approaches are probably not far off of each other,

The Lyngy’s ability to stream seems pretty good to me.
For an integrated amp, it seems to tick the boxes… and assuming that the room perfect is the same in out two products, then it just works,

For those with more complex systems than mine, the TDA 3400 can be enhanced by purchasing one or both of the optional HDMI 2.1 input/output module or the high-end analog input module. See the descriptions of these modules on this page. While I'm sure you can still buy a better phono preamp than the optional Lyngdorf module includes, you could feed the Lyngdorf the analog output of your phono preamp.

For up to eight amplifier channels and at least double the output power per channel, you could feed the balanced analog output of the 3400 into Lyngdorf's MXA 8400 multichannel amp. This amp has the same footprint as the 3400 and weighs only 22 pounds.

My system, being streaming only and using relatively high sensitivity speakers, does not need any of these options, but they are there for those who do. I specifically chose not to add the optional boards to my 3400, reasoning that in addition to the added cost and unneeded functionality, it is never helpful sonically to add additional demands to the power supply of a unit, much less any additional electrical interference within the chassis which might be caused by operation of the unneeded optional boards.

Let's talk volume control for a minute. As I've mentioned the Lyngdorf TDAI 3400 provides very capable amplification by means of a PowerDAC which produces enough voltage output to drive speakers directly, as well as sufficient amperage to enable it to "double down" its rated power output from 200 wpc at 8 ohms to 400 wpc into 4 ohms.

I've also mentioned that with the 3400 the volume/SPL you hear through your speakers or headphones is controlled by controlling the input voltage to the PowerDAC. There is no traditional analog or digital volume control present.

It has been a poorly kept secret that volume control has been a problem for high-end audio since the beginning. Analog pots vary widely in their electrical characteristics as the amount of juice they pass is varied. So-called passive volume pots are praised for the "purity" of their sound, but frequently produce bass and high frequency response changes due to the interaction of the pot's electrical characteristics with the capacitance and resistance of the interconnecting wires and impedance load of downstream components. This forces the addition of buffering circuits to avoid the downstream components "seeing" the volume control. There also is the generlly wrong-headed obsession with having tons of surplus gain available from the preamp in order to make sure to be able to drive an already high-gain power amp to its full output without maxing out the volume control. That obsession results in adding a significant gain stage to most line-level preamps. And getting the left and right pots to be exactly balanced so as to avoid de-centering the imaging/staging seems to be difficult for many designs. I'm convinced that a major part of the sonic differences between one line-level preamp and another is simply the transparency of its volume control.

In the analog domain, a good case can be made that the most transparent volume control methods involve relay-controlled stepped attenuators. Benchmark has written a white paper comparing the pros and cons of various methods of volume control, concluding, of course, that its relay-controlled stepped attenuator system, used in its HP-4 and LA-4 preamps is the best method. I've owned the HP-4 and indeed I did think it sounded superior to other analog methods for controlling volume.

And in the digital domain, despite the use of internal 24/96 processing in modern DACs, it is often common to operate a digital volume control at levels of more than 36 dB below maximum output, levels which can start to impair the resolution of the signal. Late at night I frequently play my systems with the digital volume control at minus 45 dB or even lower. For background music as heard from my computer desk outside the audio room (such as now while I'm typing this) I tend to set the Lyngdorf's volume control at minus 57 dB or lower.

As far as handling volume control in the digital domain, I was long convinced that the Leedh-DSP-processed volume control used by Lumin streamers was the most transparent volume scheme I'd heard, better yet than the Benchmark analog relay-controlled stepped attenuator method. The Leedh processing is defeatable so it is easy to compare the effects of high amounts of volume attenuation on the system sonics with just the few seconds of delay required for switching the Leedh processing in and out. The difference made by the Leedh processing is farily obvious and should be quite audible in most systems to most listeners. Of course, the better your speakers are at revealing detail at low SPL levels and the quieter your room, the more obvious the differences will be.

Very few companies other than Lumin use Leedh-processed digital volume controls. This may explain why many listeners still shun directly driving their power amps from the DAC's output, choosing instead to operate the DAC at unity gain and inserting an analog preamp downstream of the DAC to control the signal level fed to the power amp.

That brings me to the Lyngdorf method of controlling the volume. To my ears, this is the best scheme yet for controlling volume. The resolution of my system at low volumes is incredible. I hear absolutely no degradation compared to louder SPLs. This is understandable since the PowerDAC is always operating at its full 24/96 resolution regardless of the SPL I hear from the speakers. Nothing about the sound "goes away" as the volume is reduced, except, of course for Fletcher-Munson subjective effects of tonal balance. The tonal balance changes heard at lower SPLs are easy enough to compensate for through the Lyngdorf's custom voicings if so desired.

Perhaps I am more aware of this volume control transparency issue than most since the speakers I'm currently using, the Watkins Generation 4, are so very transparent themselves, having physically time-aligned drivers with a minimal first-order crossover and a uniquely damped tweeter dome, the purity of which you must hear to believe. The Lyngdorf's Room Perfect takes my room out of the equation to an unprecedented extent, allowing these speakers driven by the TDAI 3400 to sing magnificently--and at any volume from a whisper to full bore.

Last edited:
Tom, It's good to hear you are enjoying a simpler system. I do think such are the wave of the future.

It seems you have rediscovered the tremendous contribution that DRC (digital room compensation) can make, even in an excellent system. No?

Well, Mike, Room Perfect does make a subjectively very favorable difference in my room and system. It also does not interject any harm that I can hear. Part of this may relate to the "cheating" I employed by not changing the microphone position when I set up Room Perfect. In the past, with the TDAI 2170, I could never avoid Room Perfect adding an obnoxious response peak centered around 4 kHz. Either Room Perfect has been improved or my "cheating" eliminated this problem.

I also suspect that the very significant improvement Room Perfect made in my current system has much to do with the size and positioning of my Watkins Generation 4 speakers. Those speakers are only 14 inches tall. They need to be on 30-inch stands to get the middle of their cabinet up to my seated ear level of 37 inches, which is the manufacturer-recommended ideal axis, something I have verified by listening.

Given the geometry of my room and my preferred Cardas positioning for best imaging and staging, this makes the distance of the woofers from the floor and side walls about equal. This probably causes a dip in the power range (about 100 to 300 Hz) which Room Perfect is able to fill in quite nicely without any audible adverse effects.

With different speakers, like the Graham LS8/1, where the speakers are taller and the stands are much lower, the woofers are much closer to the floor. The distance of woofers to the floor is thus not approximately equal to the distance of the woofers to the side walls. I have no audible dip in the power range with those speakers without Room Perfect or other equalization.

When I switch back to the Grahams or use other speakers, I will report further on whether Room Perfect adds as much subjective benefit with other speakers as with the Watkins.

  • Like
Reactions: Holmz
I recently set up another totally separate system in another smaller-yet bedroom (about 9 x 9.5 feet with 8.5 foot ceiling) with near-field listening around a second TDAI 3400 which I picked up used from US Audio Mart. I have a 42" Sony OLED flat screen TV in there and feed its toslink digital out into the Lyngdorf. My goal of having this system is to provide better sound from this TV and to provide a means of using my Graham Audio LS81/ speakers or experimenting with vintage speakers without disturbing my current Watkins Generation 4 set up in my main audio room.

To begin with, I'm using a pair of 50 - 60 year-old Dynaco A25 speaker right now, sitting on 24-inch wood stools. Ive used these stools many times before as speaker stands and they work very well, considering they cost only about $45 each and are easy enough to put together. I let the legs sit on the carpet and use tiny vinyl dots as an interface between the speakers and the stool seat/top.

The system sounds remarkably good, given that I'm not yet using Room Perfect, the total lack of acoustic and electrical tweaking, and the age of the speakers. Their original price was about $80 a pair. I have ordered a couple of new chairs for the room which sit a bit higher. The chairs ordinarily would be placed along the wall opposite the system, one on either side of the small lamp table. One chair would be moved into a centered near-field (about 54 inches from ears to drivers and 51 inches from eyes to screen) position for "serious listening, the position shown for the old chair in the following pictures.





My wife and I call this room the "blue room" because of its deep blue walls.

This coming week I expect to receive a pair of 1996 vintage Acoustic Research AR-303a speakers to try out in this system. I'm sure the bass will go deeper, but as for the rest of the sound, we shall see. The Dyna A25s continue to impress me with their easy-on-the-ears naturalness.

Last edited:
  • Like
Reactions: ecwl
This blue room has no ethernet cable running to it and I haven't yet invested in running such a cable to that room from my router. This room also has the poorest Wi-Fi reception in my house. The Wi-Fi is good enough for streaming HD video to my Sony OLED Google TV in that room, but the "Good" signal strength indication of the TV settings leaves something to be desired in terms of speed of response to operational commands.

In addition, while the Lyngdorf is mounted about 18 inches directly below the TV on the same stand and is in open air, its Wi-Fi reception seems marginal, leading to more than occasional audio streaming dropouts.

I have for now solved this problem by installing this TP Link unit. I mounted this unit across the room in front of the room's doorway (it is the white device on the lower shelf of the small lamp table in one of the pictures in the prior post) and in that location, combined with the undoubtedly superior multiple external antennas of this unit, I get Wi-Fi download and upload speeds of 200+ mbps from the 5 GHz band. I connected the TP Link in its "Range Extender Mode." This, like its "Client Mode," allows connecting a device to the TP Link output via ethernet. That solves the 3400's connectivity problem nicely.

However, in addition, this "Range Extender Mode" allows me to connect other devices to the TP Link output via Wi-Fi. This mode basically acts as a repeater for my router's Wi-Fi signal. This works wonderfully well for the TV and iPad controller, giving me the 200+ mbps download and upload speeds to the Lyngdorf as well as the TV and iPad controller.

The ethernet wired connection is via a cheap 25-foot ethernet cable running around the periphery of the room.

My original plan was to use Wi-Fi to feed the Lyngdorf as well as the TV and iPad. I did in fact set it up that way for a short while. However, as the Lyngdorf manual states, if at all possible, you should connect the Lyngdorf via ethernet rather than Wi-Fi. There are at least three reasons for this.

First, as I again verified with the two Lyngdorfs in both rooms, the Lyngdorf sounds better when connected by ethernet than by Wi-Fi. This finding of mine has held true for a variety of network streamers over the years and the Lyngdorf proved no different. This has been my subjective judgment whether or not I use a fiber-optic device to isolate the ethernet from the streamer as I do in my main audio room or just run the ethernet straight into the streamer as I'm doing in the blue room. And note that in my blue room set up the ethernet is only the last link; the connection from the router to the TP Link device is Wi-Fi and the ethernet connection still sounds better even though the ethernet cable is 25 feet long and the Wi-Fi path length is only about 7 feet.

Second, the directions in the manual for connecting the Lyngdorf via Wi-Fi are at best ambiguous. I went through lot of fuss and bother connecting the Lyngdorf via Wi-Fi. While I eventually did figure it out, I consider the manual's directions just plain wrong. You definitely should not use what the manual calls the "Apple Wi-Fi Accessory Configuration." Doing so means that Roon will only connect via the AirPlay2 function of the Lyngdorf, thereby limiting the resolution of the Lyngdorf's streaming functions to 44.1/16, defeating the ability to listen in higher resolutions up to 192/24.

Third, entering a Wi-Fi password via the Lyngdorf is not explained in the manual and is tedious and easy to do incorrectly. The TDAI 3400 has to be teased and cajoled to connect to my network via Wi-Fi. With ethernet, it connects first time, every time. Rather than explain the Wi-Fi connection process, which I eventually did figure out, I will just reiterate: connect the TDAI 3400 to your home network via ethernet rather than Wi-Fi. The TP-Link device provides a way to do this in most situations and only costs about $45, plus a few dollars for an ethernet cable.
