This is only on the 101D setting. On the 300B setting, it's instantaneous, but that isn't the preferred setting so...
Well in my Rod Coleman modded DAC they ALL take ages to start working.
But prior to that mod, AD1n took a while. So did the EML AD1. I don't believe it could supply the correct current, as observed by the guy that did the Coleman mod, but I am not sure that's the reason they took so long.
But prior to that mod, AD1n took a while. So did the EML AD1. I don't believe it could supply the correct current, as observed by the guy that did the Coleman mod, but I am not sure that's the reason they took so long.
Do you mean Western Electric? I'm not sure it's usable in a Lampi, hopefully someone can confirm.
It has the same heater and current ratings as 300B so it should be a brilliant match.
Could be an excellent valve.
WE as you said. But I just checked PSvane 275A WE 1:1 replica and they state for their "take" 2.5V and 2.5A which I would say is a no go for Lampi...
Lest you have an older Lampi Big 7 or Lampi Level 7 two box then yes.
Psvane are saying theirs is a 2A3 replica. But the WE definitely isn't a 2A3. Bizarre. Anyone understand this?
https://www.radiomuseum.org/tubes/tube_275a.html
Seems PSvane played a bit too much...WE has a spec you mentioned and that one is OK. PSvane same model to be avoided...
Ah. Here we go. Psvane BS:
Descriptions: Psvane WE275 Replica – equivalent to 2A3: The 275A tube is often referred by audiophile as ‘baby 300B’ due to its silky sound. It was one of Western Electric’s early directly heated triodes and used in PP & SE circuits of the 1930?s portable high fidelity, theater sound amplifiers – like the “silver” circa 1935 Western Electric D95508 portable amp. The original WE275A tubes has heater voltage at 5V and was not widely used in home stereo; In this new Psvane WE Replica 275 tube, Psvane Audio has modified the tube heater voltage to the standard 2.5V then you can use it to replace a typical 2A3 tube – which is of smaller glass enclosure size than 300B tube
Descriptions: Psvane WE275 Replica – equivalent to 2A3: The 275A tube is often referred by audiophile as ‘baby 300B’ due to its silky sound. It was one of Western Electric’s early directly heated triodes and used in PP & SE circuits of the 1930?s portable high fidelity, theater sound amplifiers – like the “silver” circa 1935 Western Electric D95508 portable amp. The original WE275A tubes has heater voltage at 5V and was not widely used in home stereo; In this new Psvane WE Replica 275 tube, Psvane Audio has modified the tube heater voltage to the standard 2.5V then you can use it to replace a typical 2A3 tube – which is of smaller glass enclosure size than 300B tube
I mentioned somewhere that it is unobtainable at least until ‘21
I have a Shuguang GZ 480 I can sell. It arrived with a loose piece of glass from the interior base (I can see exactly where it came from). Between the time I ordered it and the Rectifier arriving, I sold my Pac, so I haven't been able to test it. I'll offer a full refund if it doesn't function as it should. All the interior parts seem to be in perfect shape, so I think it will likely work fine. PM if interested in making an offer.
Got my paws on a matched pair of AVVT 302b SL
datasheet below
http://www.elektronenroehren.de/avvt/datashts/av302b.htm
5v, 2.2 amp
so 300B/T-1000 setting?
datasheet below
http://www.elektronenroehren.de/avvt/datashts/av302b.htm
5v, 2.2 amp
so 300B/T-1000 setting?
I just got my pair of AD1s. Is there a specific way to get them into the adapters? I am afraid to push too hard but it does seems like I will have to apply some force. Should I put them in straight or does one edge go in before another.
Also, which heater setting should I be using in my Big 7 MKII? 300B or 45/242?
Also, which heater setting should I be using in my Big 7 MKII? 300B or 45/242?
David never push them straight down...tilt the tube towards one direction to snap with the base and then just straighten it up...should be fairly easy...
For selector - check what i wrote in one of the posts regarding heater V and A and you’ll figure it out...is it Tesla? If Tesla ad1n then its not the same setting as for Phillips ad1 - take care of that!
Cheers
For selector - check what i wrote in one of the posts regarding heater V and A and you’ll figure it out...is it Tesla? If Tesla ad1n then its not the same setting as for Phillips ad1 - take care of that!
Cheers
